* WC1602T7DVN6G is a Monochrome color COG type FSTN negative,Transmissive LCD.
* It is composed of a monochrome LCD panel, driver IC, FPC, and backlight.
*It is 16character x2line monochrome character FSTN lcd monitor.
* Backlight with white,blue,yellow,red color
* Specific touch panel can be designed & customized.
* RoHS & REACH compliant.
LCD Name
Very small FFSTN lcd display negative 1/16 duty character LCD screen 16x2 monochrome lcd
Display Format
16 characters x 2lines
Display Mode
FSTN negative, Transmissive
Driver IC
NT7605
Surface Treatment
Anti-glare
Outline Dimension
69.5x27.4x2.85
Viewing Area
64.5x14.4
Viewing Direction
6 O’clock
LCD Interface
I2C
Backlight
White LED backlight
Driving Method
1/16 Duty, 1/5 Bias
Working Temp.
-20℃~+70℃
Storage Temp.
-30℃~+80℃
Company Information
Packaging & Shipping
FAQ
1.Q: Order process A:PO is placed by clients → PI is issued by Formike → Payment by clients → Lead time is confirmed by Formike → Shipping instrction by Clients → Delivery → Cargo tracking → Receipt of cargo
2.Q: Lead time ( after payment is confirmed) A: Sample: 1-10 working days Volume: 3-60 working days
3.Q: Payment A: T/T , Western union, L/C, Credit card, and Cash
4.Q: Warranty A: 12 months warranty ( Please find more details via our datasheet by item of Limited Warranty)
5.Q:RMA Process A:Claimed by cliens with photos or videos → Sales rep of Formike confirm if have questions → Sales rep issue RMA No to clients if confirmed by QA → Return to Formike → Formal report after goods received by Formike → Clients confim the analysis report → Proceeding as per the Report both agreed
6.Q:Notes A:Please check both appearance and function of products prior to installation. Any damage caused by improper use or unprofessional installation is not covered under warranty.
